6FSR40/30B – Crabtree Loadstar 40A Type B 30mA 6kA Type A RCBO (Single Module)

6FSR40/30B — Crabtree Loadstar 40A Type B 30mA 6kA Type A RCBO

The Crabtree Loadstar 6FSR40/30B is a single module RCBO providing combined MCB and RCD protection in one compact unit. Rated at 40A with a B curve trip characteristic, 30mA Type A earth leakage protection and 6kA short-circuit breaking capacity to EN 61009-1.

Designed for use in Crabtree Loadstar distribution boards, this RCBO occupies just one module width, saving valuable board space. Single pole switching with switched neutral.

We currently have 14 units available.

• 40A B curve MCB
• 30mA Type A RCD protection
• 6kA rated short-circuit breaking capacity (EN 61009-1)
• Single module width (SPN)
• 230V AC, 50Hz
• IP20 rated
• Terminal capacity: 0.75–16mm²
• CE, UKCA and WEEE compliant
• For use with Crabtree Loadstar distribution boards
