ADA140U – Hager Compact RCBO 40A 30mA 10kA B Curve
£24.00 inc VAT
- One year full guarantee. Fourteen day no questions return.
- Delivery £7.00 ex VAT
- FREE delivery on orders over £120.
- SSL secure transactions
- Call us today for any advice
Product Description
ADA140U – Hager Compact RCBO 40A 30mA 10kA
The ADA140U is a compact RCBO from Hager, designed to provide reliable protection for electrical circuits with a 40A rated current. Combining overcurrent and residual current protection, this RCBO ensures safety and compliance in residential and commercial electrical installations. With a compact design and robust features, it’s an ideal solution for modern switchboards and consumer units.
Key Features
- Type B Tripping Curve: Suitable for circuits with appliances generating pulsating DC components, such as washing machines and variable speed drives.
- 30mA Tripping Sensitivity: Protects against earth leakage currents, reducing the risk of electric shock.
- 10kA Breaking Capacity: Safely interrupts short-circuit currents up to 10,000 amps.
- DIN Rail Mounting: Allows for quick and secure installation in consumer units or distribution boards.
- Compact Size: Single-module design saves space, making it ideal for compact switchboards.
- Flying Neutral Lead: Simplifies the connection of the neutral conductor for easy installation.
Technical Specifications
- Rated Voltage: 230/240V AC
- Rated Insulation Voltage: 250V
- Maximum Operating Voltage: 253V
- Rated Impulse Withstand Voltage: 4000V
- Rated Current: 40A
- Pollution Degree: 2
- Enclosure Class: IP20
- Operating Temperature Range: -25°C to +40°C
- Storage Temperature Range: -40°C to +70°C
- Dimensions: 115mm (H) x 17.5mm (W) x 70mm (D)
The ADA140U combines advanced safety features, compact design, and ease of installation, making it an excellent choice for protecting electrical circuits with a higher rated current. Trust Hager for high-quality circuit protection devices designed to meet modern safety standards.
